MicrocomputerApplicationsVol.39,No.11,2023文章编号:1007-757X(2023)11-0073-03基金项目进气型式对并联旋风分离器流场的影响微型电脑应用2023年第39卷第11期张爱琴1,周建龙²,张建广1(1.西安航空职业技术学院,航空制造工程学院,陕西,西安710089;2.西安煤矿机械有限公司,掘进机设计所,陕西,西安710018)摘要:采用FLUENT软件模拟催化裂化三旋中并联旋风分离器进气型式的不同对内部流场的影响,主要对比了不同进气型式下入口处的流场分布、分离空间内的切向速度与压降的差异。研究结果表明,采用U型进气型式,分离器压降与速度略大,且比较容易引起环形空间内不利于分离器的二次流动;采用D型进气型式,分离器芯管下口处向内的径向速度较大,容易形成“短路流”。2种进气型式均会造成入口处的涡流,在气固分离过程导致颗粒的沉积以及管道的磨损,其对分离效率的影响有待试验进一步测量。关键词:旋风分离器;催化裂化三旋;内部流场;进气型式中图分类号:TQ053.2InfluenceofInletTypeonFlowFieldofCyclonesinParallel(1.DepartmentofAeronauticalManufacturingEngineering,Xi'anAeronauticalPolytechnicInstitute,Xi'an710089,China;2.RoadHeaderDesignInstitute,Xi'anCoalMiningMachineryCo.,Ltd.,Xi'an710018,China)Abstract:Theinfluenceoftheinlettypeonperformanceoftheparallelcyclonesisdiscussed.Theflowfielddistributionattheinletunderdifferentinlettypesandthedifferencesoftangentialvelocityandpressuredropintheseparationspacearemainlycompared.Theresultshowedthatthepressuredropandvelocityinup-inlet-typeareslightlyhigherthanthatofthedown-inlet-type,andasecondaryflowiseasilyproducedintheannularspaceinup-inlet-typewhileashortcircuitflowisfoundindown-in-let-type.Boththetwoinlettypescausecrossflow,whichmayleadtoparticledepositionandpipewearintheprocessofgas-solidseparation.Theinfluenceofthepatternofinlettubeontheseparationefficiencyneedstobetestedandfurthermeasured.Keywords:cyclone;FCC;internalflowfield;inlettype的速度分布,对并联旋风分离器内部流场产生了很大的影0引言响。针对上述问题与设想,本文采用数值模拟的方法,系统旋风分离器是一种利用离心力进行气固分离的设备,结研究上进气(U)、下进气(D)对并联旋风分离器气相流场的构简单、无运动部件、维护方便、价格低廉...
