水处理与注水工程张祎达等:基于FSA的相邻罐消防冷却水系统设计探讨油气田地面工程https://yqtd.cbpt.cnki.net基于FSA的相邻罐消防冷却水系统设计探讨张祎达孙龙珠连广宇中国石油工程建设有限公司北京设计分公司摘要:罐区消防冷却系统是油田站场消防设计重点,结合中东地区某油田罐区消防冷却保护设计实例,解决相邻罐设计问题。通过对比国内外标准发现,在确定相邻罐设计固定式冷却喷淋系统方面,国内外均采用罐壁之间间距是否大于N倍罐直径的设计原则;在消防冷却喷淋强度及面积设计方面,总体趋势为我国标准体现冷却喷淋强度低,罐壁冷却面积大;国际标准体现冷却喷淋强度高,罐壁冷却面积小,考虑罐壁上半部分气相空间冷却。同时,国际上引入火灾安全分析(FSA)复核消防冷却设计方案,通过软件模拟不同火灾工况下的相邻罐表面热辐射强度,按热辐射强度超过12.5kW/m2,则需考虑设计固定冷却喷淋系统,可结合事故泄漏发生频率高低、工程投资费用等进行最终确定。通过火灾安全分析复核,罐区消防冷却设计满足要求,得出在风险可接受条件下的消防设计方案,为项目投资决策提供技术支持,保障项目后续运行阶段平稳顺利。关键词:相邻罐消防冷却系统;热辐射强度;喷淋强度及面积;火灾安全分析(FSA)DiscussionontheDesignofAdjacentTankFireCoolingWaterSystemBasedonFSAZHANGYida,SUNLongzhu,LIANGuangyuBeijingDesignBranch,CPECCAbstract:Thefirecoolingsystemintankareasisakeyfocusoffireprotectiondesignforoilfieldsta-tions.CombiningwiththefirecoolingprotectiondesignexampleofanoilfieldtankfarmintheMiddleEast,thedesignproblemofadjacenttanksissolved.Bycomparingdomesticandforeignstandards,itisfoundthatindeterminingthedesignoffixedcoolingspraysystemsforadjacenttanks,bothdomesticandforeigndesignprinciplesarebasedonwhetherthespacingbetweentankwallsisgreaterthanNtimesthetankdiameter.Intermsoffirecoolingsprayintensityandareadesign,thegeneraltrendisthatChinesestandardsreflectlowcoolingsprayintensity,largetankwallcoolingarea,consideringthegasphasespacecoolingontheupperhalfofthetankwall,internationalstandardsreflecthighcoolingsprayintensity,smalltankwallcoolingarea.Atthesametime,internationally,firesafetyanalysisisintro-ducedtoreviewfirecoolingdesignschemes,and...
