南京航空航天大学硕士学位论文模块化UPS研究姓名:王亮平申请学位级别:硕士专业:电力电子与电力传动指导教师:邢岩20090201南京航空航天大学硕士学位论文i摘要近几年来,模块化可并联UPS电源系统在各电力行业、通信运行企业中得到了较为广泛的应用,它具有高可靠性、易拓展性、便于维护性和供电灵活等优点。本文分析研究了在线式UPS系统中的TL-HBPWM整流器模块和三电平半桥逆变器模块。对于TL-HBPWM整流器,首先分析研究了整流器的SPWM调制策略,然后分析了整流器的双闭环控制;通过对数字控制整流器中调制波与输出电压关系的分析,研究了中点电位平衡控制策略;最后研究了整流器的并联控制策略。对于TL-HB逆变器,首先简单分析了双闭环控制加重复控制的复合控制方法;然后研究了逆变器的同步控制策略,提高了同步控制精度;最后研究了逆变器的分布式并联控制策略。设计完成了1台基于DSP的1KVAUPS原理样机,给出了硬件电路和软件程序的设计方法,并以此样机为平台进行了相关实验,实验结果验证了上述分析与研究的正确性和合理性。关键词:三电平半桥,模块化,中点电位平衡控制,并联,同步控制模块化UPS研究iiAbstractInrecentyears,themodularizedparallelingUPSpowersupplysysteminthepowerindustryandtelecommunicationscompanieshavebeenappliedwidely,ithassomeadvantages:highreliabilityandeasyexpansion,easytomaintainandflexibilityofpowersupplyandsoon.Inthisthesis,theTL-HBPWMrectifierandTL-HBinverterareresearched.ForTL-HBPWMrectifier,theSPWMstrategyoftherectifierisresearchedfirstly,andthenthedual-loopcontrolforitisanalyzed;Accordingtotherelationofmodulationwaveandoutputvoltageindigitalcontrolrectifier,thestrategyoftheneutralpointvoltagebalancingisberesearched;Finally,theparallelstrategyofrectifierisresearched.ForTL-HBinverter,thehybridcontrolstrategybasedonvoltage-currentdual-loopcontrolandrepetitivecontrolisanalyzedfirstly,andthenthesynchronizationcontrolisresearchedtoenhancetheprecisionofsynchronization;Finally,thedistributingparallelcontrolstrategyisresearched.A1KVAprototypeofUPSisbuildanddesignmethodsofhardwarecircuitandsoftwareprogramarepresented.Theexperimentalresultsbasedonthisprototypeareprovided,bywhichthevalidityandfeasibilityofcontrolschemear...
