电子质量2022年第12期(总第429期)水下交流电磁场便携式智能检测仪王强1,王伟斌1,杨冬平1,郭敏1,王运才2,马维平2(1.中国石油化工股份有限公司胜利油田分公司,山东东营257000;2.中国石油大学(华东)海洋油气装备与安全技术研究中心,山东青岛266580)摘要:首先,在交流电磁场检测(ACFM)技术的基础上,以水下金属结构裂纹类缺陷为主要研究对象,设计优化了水下ACFM探头模块和水下舱体模块;然后,对软件、电路、信号处理系统和相关的硬件进行了系统搭建,通过智能判定程序实现信号显示、提离抖动抑制和缺陷智能判定;最后,研发了一套水下ACFM便携式智能检测仪器。结果表明:该便携式检测仪器实现了以太网的数据传输,可以在50m深的海水中正常工作,实现水下裂纹的智能报警和显示,提高了仪器的集成化水平与便携性,具有一定的工程实用价值。关键词:水下交流电磁场检测;缺陷检测;抖动抑制;智能判定;仪器研发中国分类号:TP202文献标识码:A文章编号:1003-0107(2022)12-0082-09PortableIntelligentDetectorforUnderwaterAlternatingCurrentFieldMeasurementWANGQiang1,WANGWeibin1,YANGDongping1,GUOMin1,WANGYuncai2,MAWeiping2(1.ChinaPetroleumandChemicalCorporationShengliOilfieldBranch,Dongying257000,China;2.CenterforOffshoreEngineeringandSafetyTechnology,ChinaUniversityofPetroleum(EastChina),Qingdao266580,China)Abstract:Firstly,basedontheACFMtechnology,takingthecracksofunderwatermetalstructureasthemainresearchobject,theunderwaterACFMprobemoduleandunderwatercabinmodulearedesignedandoptimized.Then,thesoftware,circuit,signalprocessingsys-temandrelatedhardwarearesystematicallybuilt,andthesignaldisplay,liftingjittersuppres-sionanddefectintelligentjudgmentarerealizedthroughtheintelligentjudgmentprogram.Final-ly,asetofunderwaterACFMportableintelligentdetectioninstrumentisdeveloped.TheresultsshowthattheportabledetectioninstrumentrealizesthedatatransmissionofEthernet,anditcanworknormallyin50mdeepseawater,realizestheintelligentalarmanddisplayofunderwatercracks,andimprovestheintegrationlevelandportabilityoftheinstrument,soithascertainengineeringapplicationvalue.Keywords:underwaterACFM;defectdetection;jitters...
